Surface Mount Signal Relay, 48V dc Coil, 2A Switching Current, 4PST

Coil Voltage:

48V dc

Contact Configuration:

4PST

Mounting Type:

Surface Mount

Maximum Switching Current DC:

2 A

Maximum Switching Voltage AC:

125V ac

Maximum Switching Voltage DC:

150V dc

Series:

Cradle N

Maximum Switching Power DC:

70 W

Length:

30mm

Latching:

No

Depth:

19mm

Height:

30mm

Dimensions:

19 x 30 x 30mm

Terminal Type:

Through Hole

Number of Poles:

2

Switching Current:

2A

Application:

Power

Coil Power:

800mW

Coil Resistance:

2500Ω

Isolation Coil To Contact:

500V

Maximum Operating Temperature:

+70°C

Minimum Operating Temperature:

-40°C

Features:

Multi Purpose Relay, Highly Reliable

Contact Material:

Silver Nickel Alloy

Operating Temperature Range:

-40 → +70°C

Maximum Switching Power AC:

50VA
