DC-DC Switching Regulator, Through Hole, 9V dc Output Voltage, 14 → 72V dc Input Voltage, 500mA Output

Output Voltage:

9V dc

Output Current:

500mA

Input Voltage:

14 → 72V dc

Mounting Type:

Through Hole

Number of Outputs:

1

Package:

SIP

Efficiency:

86%, 92%

Ripple And Noise:

75mV Pk-Pk

Minimum Temperature:

-40°C

Maximum Temperature:

+85°C

Series:

SRH05

Line Regulation:

1%

Maximum Input Current:

3 mA, 75 mA, 350 mA

Width:

10.16mm

MTBF:

4.5Mh

Depth:

7.5mm

Length:

11.68mm

Standards Met:

EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, MIL-HDBK-217F

Protection Features:

Short Circuit Protection

Switching Frequency Range:

120 → 800kHz

Load Regulation:

0.6%

Power Signal Conversion Type:

DC-DC

Weight:

2.1g
