tl49w0050 APEM Toggle Switch, PCB Mount, On-Off-On, DPDT, Through Hole Terminal, 20 V dc, 20 V ac
tl49w0050 APEM Toggle Switch, PCB Mount, On-Off-On, DPDT, Through Hole Terminal, 20 V dc, 20 V ac
tl49w0050 APEM Toggle Switch, PCB Mount, On-Off-On, DPDT, Through Hole Terminal, 20 V dc, 20 V ac

The APEM TL49W0050 DPDT (double‑pole double‑throw) toggle switch delivers reliable and precise control across global applications. With an On‑Off‑On configuration, compact PCB mounting, and gold‑plated brass terminals, it offers exceptional electrical performance and durability. Engineered to withstand temperatures from –30 °C to +85 °C and featuring low contact resistance (0.02 Ω) alongside a 400 mA @ 20 V DC rating, this miniature switch ensures seamless integration in electronic devices worldwide.

Why Choose the APEM DPDT Toggle Switch?

The APEM TL49W0050 stands out for its balance of precision, robustness, and versatility. Its DPDT configuration enables simultaneous control of two circuits, ideal for complex systems. Gold‑plated brass contacts ensure excellent conductivity and resistance to corrosion, while its sealed, wave‑solderable design endures rigorous assembly and environmental demands, perfect for global markets requiring both reliability and compact form factor.

Salient Features and Benefits of the Product

  • Dual‑circuit control: DPDT On‑Off‑On setup allows versatile switching functions.
  • Superior conductivity: Gold‑plated brass contacts and low resistance (0.02 Ω) for efficient signal transfer.
  • Wide temperature tolerance: Operates reliably from –30 °C to +85 °C.
  • Compact and PCB-friendly: Through-hole mount with 5.3 mm actuator fits space-constrained designs.
  • Durable and sealed: Resistant to cleaning and wave soldering; built for longevity.

Versatility in Applications

  • Consumer electronics (e.g., audio gear, handheld devices)
  • Industrial control panels and automation systems
  • Computing equipment such as servers and network hardware
  • Automotive electronics requiring compact, resilient switching
  • Medical devices and precision instrumentation
  • Embedded systems and PCB-based control units

RoHs Compliant

Apem TL49W0050 APEM Toggle Switch, PCB Mount, On-Off-On, DPDT, Through Hole Terminal, 20 V dc, 20 V ac

Manufacturer:
Apem
Manufacturer Part No:
TL49W0050
Enrgtech Part No:
ET13979857
Warranty:
Manufacturer
local
26 - In Stock

Ships in 2-3 business days

pcs

Quantity
Unit Price (ex VAT)
1
£ 7.73 £ 5.41
Order Today!
From: United Kingdom
Est Ship Date: 13 Sep, 2026
Est Fastest Delivery: 14 Sep, 2026
Width:
8.1mm
Height:
19.58mm
Length:
9.6mm
Series:
TL
Mount Type:
PCB
Illuminated:
No
Product Type:
Toggle Switch
Terminal Type:
Through Hole
Actuator Length:
5.3mm
Switch Operation:
On-Off-On
Actuator Material:
Brass
Contact AC Voltage:
20V ac
Contact DC Voltage:
20V dc
Standards/Approvals:
RoHS
Switch Configuration:
On-Off-On
Contact Configuration:
DPDT
Switch Contact Current:
400mA
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-30°C
Mounting Type:
PCB
Terminal Type:
Through Hole
Actuator Length:
5.3mm
Contact Material:
Gold Plated Brass
Switch Operation:
On-Off-On
Actuator Material:
Brass
Contact Resistance:
0.02Ω
Contact Configuration:
DPDT
Contact Current Rating:
400 mA @ 20 V dc
Operating Temperature Range:
-30 → +85°C
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-30°C
Explore toggle switches engineered for durable performance and control. Enrgtech offers reliable switching components for electrical and electronic applications.
