PAXLV Voltmeter
The PAXLV Voltmeter is a premium quality instrument designed for tough industrial applications. With multi-range capability, built-in provision for scaling and DIP switch selectable decimal points, this meter offers the ultimate in application flexibility. The voltmeter can provide direct readout from pressure, speed or flow transducers or any other variable that can be translated to voltage.
3.5-digit (14.2 mm) red LED display
Built-in scaling provisions
Selectable decimal point location
Auto zeroing circuits
Over-range indication
Optional custom units overlay with backlight
NEMA 4X/IP65 sealed front bezel
Built-in scaling provisions
Selectable decimal point location
Auto zeroing circuits
Over-range indication
Optional custom units overlay with backlight
NEMA 4X/IP65 sealed front bezel
PAX Series Digital Voltmeter AC, LED Display 3.5-Digits ±0.1 %
£ 189.20
Checking for live stock
Current Type:
AC
Number of Digits:
3.5
Display Type:
LED
Cutout Height:
45mm
Cutout Width:
92mm
Depth:
104.1mm
Digit Height:
14.2 mm
Meter Accuracy:
±0.1 %
Analogue Effect:
Digits Only
Minimum Temperature:
0°C
Meter Type:
Voltmeter
Maximum Temperature:
+60°C
